| CPU |
- 13th gen Intel® Core™ i9/i7/i5/i3 processor, up to 65W TDP
|
| Chipset |
|
| System Memory |
- 2 x 260-pin DDR4-3200 SO-DIMM, up to 64GB with ECC support
|
| Graphics |
|
| BIOS |
|
| COM |
- 2 x RS-232/422/485 (with +5/12V power)
|
| USB |
- 4 x USB 3.2 Gen 2x1 Type-A
|
| Ethernet |
- 2 x 10/100/1000/2500 Mbps Ethernet (Intel® I226-LM; Intel® AMT)
|
| Display |
- 2 x HDMI 1.4b (4096 x 2160 @30Hz)
- 1 x DisplayPort++ 1.2 (4096 x 2160 @60Hz)
|
| Audio |
|
| Storage |
- 2 x 2.5" hot-swappable SATA III drives with RAID 0/1 support
- 1 x M.2 Key M 2280 NVMe SSD slot
|
| Expansion |
- 1 x Double-width PCIe x16 slot with PCIe x8 Gen4 signal supporting various GPU cards
- 1 x PCIe x16 slot with PCIe x8 Gen4 signal
- 1 x M.2 Key E 2230
- 1 x M.2 Key B 3052/3042
|
| Others |
- 1 x Power button with LED indicator
- 2 x SMA-type antenna connector (optional)
|
| TPM |
|
| Power Supply |
- 100 to 240V AC input, 500W/900W medical-grade PSU
|
| Watchdog Timer |
|
| Operating Temperature |
- 0°C to 40°C (32°F to 104°F)
|
| Relative Humidity |
- 10% to 90%, non-condensing
|
| Vibration Endurance |
|
| Dimensions (W x D x H) |
- 310 x 332 x 145mm (122" x 131" x 57")
|
| Weight (net/gross) |
|
| EOS Support |
- Windows® 10, Windows® 11, Linux
|
| Certifications |
- CE, FCC Part 18
- IEC60601-1 Ed3.2 compliance
|
