| Bus Type |
|
| Connector |
- 2 or 4 GbE LANs (M12 x-coded) by Intel® i210-AT controller, support 9.5KB jumbo frame and IEEE 1588
- IEEE 802.3at compliant, each port delivers up to 30W at 54 VDC
|
| Power Connector |
- 4-pin Molex & 6-pin ATX power connector
- 12 VDC or 24 VDC
|
| Power Requirements |
- Power from PCIe slot (max. 20W PoE power output)
- 2.1A @ +12V
- 1.2A @ +3.3V
- Power from ATX power connector (max. 120W PoE power output)
- 12A @ +12V or 6A @ +24V
- 1.2A @ +3.3V (from PCIe slot)
- Power from Molex power connector (max. 60W PoE power output)
|
| Operating Temperature |
- 0°C to +60°C (+32°F to +140°F) (with airflow)
|
| Relative Humidity |
- 10% to 95%, non-condensing
|
| Dimensions |
|
| Certifications |
|
| Software |
|
| OS |
- Windows® 7/10 (32/64-bit)
|
