| CPU |
- Intel® Celeron® processor J1900 2.00 GHz
|
| Chipset |
|
| System Memory |
- 1 x DDR3L-1333/1600 SO-DIMM, up to 8GB
|
| COM |
|
| USB |
|
| Ethernet |
- 2 x RJ-45 isolated*10/100/1000 Mbps (Intel® i211-AT)
|
| PoE |
|
| CANbus |
|
| Digital I/O |
- 1 x DB9 DI/DO (8-bit programmable)
|
| Analog Input |
|
| Display |
|
| Expansion |
- 1 x Full-size PCI Express Mini Card slot
- 1 x SIM card socket
|
| Storage |
- 1 x CompactFlash™ (or mSATA)
- 1 x SATA SSD (or HDD)
|
| Others |
|
| Power |
|
| Watchdog Timer |
- 255 levels, 1 to 255 sec.
|
| Construction |
- Extruded aluminum and heavy-duty steel, IP30
|
| Operating Temperature |
|
| Relative Humidity |
- 0% to 95%, non-condensing
|
| Vibration |
- 2 Gms (5 to 500Hz, amplitude 0.35 mm; operation/storage/transport)
|
Dimensions
(W x D x H) |
|
| Weight (net/gross) |
- 1.0 kg (2.2 lb)/1.50 kg (3.3 lb)
|
| Certifications |
|
| EOS Support |
- Windows® 7 Embedded
- Windows® 8 Embedded
- Linux support package
- Windows® 10 IoT core pro
|
| Software Support |
|
| Mounting |
|
