| CPU |
- 7th/6th gen Intel® Core™ i7/i5/i3 & Celeron® processor, up to 65W (Kaby Lake/Skylake)
|
| Chipset |
|
| System Memory |
- 2 x DDR4-2133/2400 un-buffered SO-DIMM, up to 32GB
|
| BIOS |
|
| COM |
|
| USB |
|
| Ethernet |
- 2 x 10/100/1000 Mbps Ethernet (Intel® i211-AT)
|
| Display |
|
| Digital I/O |
|
| Audio |
- 1 x Audio (Mic-in/Line-out)
|
| Storage |
- 2 x 2.5" swappable HDD (15 mm height)
|
| Expansion |
|
| Others |
- 1 x Switch for power on/off (ATX)
- 1 x Remote switch
- 1 x Reset switch
- 1 x 3-pin terminal block
- 1 x AT/ATX selectable switch
|
| Power |
- Type: ATX/AT
- Input: 24 VDC (uMin=19V/uMax=30V)
|
| Construction |
- Aluminum extrusion heavy-duty cold-rolled steel, IP40 (w/o fan module)
|
| Operating Temperature |
- -20°C to +80°C (-4°F to +176°F)
|
| Relative Humidity |
- 10% to 90%, non-condensing
|
Dimensions
(W x H x D) |
- 83.5 mm x 192 mm x 234 mm
|
| Weight (net/gross) |
|
| Software Support |
|
| Certifications |
|
