| CPU |
- Freescale i.MX6 Series SoC with Quad/DualLite/Solo ARM Cortex™-A9 CPU 800 MHz/1 GHz (only Solo)
|
| Chipset |
|
| System Memory |
- Onboard DDR3-1600, up to 1GB
|
| BIOS |
|
| COM |
- 4 x COM with TX/RX/RTS/CTS (1 with 3.3V TTL level)
- 1 x Console port
|
| USB |
- 1 x USB 2.0
- 1 x OTG client
|
| Ethernet |
|
| Display |
- 1 x 24-bit TTL signal
- 2 x Signal channel 24-bit LVDS
- 1 x HDMI 1080P
|
| Audio |
- 1 x Audio (Mic-in/Headphone)
|
| GPIO |
|
| I2C |
|
| CAN |
|
| SPI |
|
| Storage |
- 1 x eMMC flash 4 GB
- 1 x SDIO interface
- SATA interface (Quad cores CPU)
|
| Expansion |
|
| Others |
|
| Battery |
- Battery on the Baseboard is required
|
| Power Requirement |
|
| Watchdog Timer |
|
| Hardware Monitoring |
|
| Operating Temperature |
- -40°C to +85°C (-40°F to +185°F)
|
| Relative Humidity |
- 10% - 95%, non-condensing
|
| Dimensions |
|
| Board Thickness |
|
| Certifications |
|
